Helical worm gearbox R series CBN
By assembling a worm gearbox of the R series to a series of gearboxes, we obtain this series of gearboxes named CBNR.
This is the ideal choice for applications that require higher output torque and slower reduction ratios than those achievable with the equivalent gearboxes of the R series.
All of the accessories from the R series are available, such as the high output load bearings, torque limiter, output shafts and torque arms.
Main features
Great price/quality ratio
High perfomances in continual use
Flexibility in applications
High output torque
Full customization available
Specifications
-
Ratio
Min 1/38 - Max 1/3322
-
Torque (Nm)
Min 31 - Max 1000
-
Power (Kw)
Min 0.01 - Max 3.80
